RV Reducer WRV -E Series

The RV reducer is an evolution of the traditional cycloid drive. It utilizes a two-stage reduction structure combining planetary and cycloid gears, resulting in a range of exceptional features including high rigidity, high precision, high load capacity, high reduction ratio, and compact size.

Product Features

  • Built-in angular contact ball bearing mechanism improves reliability and reduces total cost

    Angular contact ball bearings are installed, so they can support external loads, have strong bending moment rigidity, and allow large bending moments; the number of required parts can be reduced and installation is easy

  • Two-stage reduction mechanism

    The orbital speed of the cycloid wheel is slowed down, and the vibration is small; the motor is directly connected to the input gear, and the inertia is small

  • Planetary carrier support mechanism

    High torsional rigidity, low vibration, and strong impact resistance

  • Roller bearing contact mechanism

    Low starting torque, low wear, long life, and small tooth gap (1 arc.min)

  • Cycloid wheel and pinion mechanism

    Small tooth gap and strong impact resistance: The multi-tooth meshing of the cycloid wheel and pinion can effectively resist impact loads.

Download

MODEL Planet carrier rotation/行星架旋转 Pin gear housing rotation/针齿壳旋转 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Output torque/输出转矩 Input power/输入功率 Representative value of bending moment stiffness/弯矩刚性代表值 Nm/arc.min.(kgf-m/arc.min.) Allowable bending moment/容许弯矩
Nm(kgf-m)		 Instantaneous maximum allowable bending moment/瞬时最大容许弯矩
Nm(kgf-m)		 Maximum allowable output speed/容许最高输出转速
r/min		 Permissible torque when starting or stopping/启动、停止时的容许转矩
Nm(kgf-m)		 Instantaneous maximum allowable torque/瞬时最大容许转矩
Nm(kgf-m)		 Empty空程
MAX.
Arc.min.		 Representative value of torsional stiffness/扭转刚度代表值
Nm/arc.min.
(kgf-m/Arc.min.)		 weight/重量
Kg
Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW Nm
(kgf-m)		 kW
Output speed/输出转速(r/min)n) 5 10 15 20 25 30 40 50 60
WRV20E 57 56 231
(23.6)		 0.16 188
(19.2)		 0.26 167
(17.0)		 0.35 153
(15.6)		 0.43 143(14.6) 0.50 135(13.8) 0.57 124(12.7) 0.7 115(11.8) 0.81 110(11.2) 0.92 372
(38)		 882
(90)		 1764
(180)		 75 415
(42)		 833
(85)		 1′ 49(5) 4.7
81 80
105 104
121 120
141 140
161 160
WRV40E 57 56 57.2
(58.4)		 0.40 465
(47.4)		 0.65 412
(42.0)		 0.86 377
(38.5)		 1.05 353(36.0) 1.23 334
(34.1)		 1.40 307
(31.3)		 1.71 287
(29.3)		 2.00 271
(27.7)		 2.27 931
(95)		 1666
(170)		 3332
(340)		 70 1029
(105)		 2058
(210)		 1′ 108(11) 9.3
81 80
105 104
121 120
153 152
WRV80E 57 56 1088
(111)		 0.76 885
(90.3)		 1.24 784
(80.0)		 1.64 719
(73.4)		 2.01 672(68.6) 2.35 637
(65)		 2.67 584(59.6) 3.26 546(55.7) 3.81 517(52.8) 4.33 1176
(120)		 2156
(220)		 4312
(440)		 70 1960
(200)		 3920
(400)		 1′ 196(20) 13.1
81 80
101 100
121 120
153 152
WRV110E 81 80 1499
(153)		 1.05 1215
(124)		 1.70 1078
(110)		 2.26 990
(101)		 2.76 925
(94.4)		 3.23 875(89.3) 3.67 804
(82.0)		 4.49 1470
(150)		 2940
(300)		 5880
(600)		 50 2695
(275)		 5390
(550)		 1′ 294(30) 17.4
111 110
161 160
175.28 174.28
WRV160E 81 80 2176
(222)		 1.52 1774
(181)		 2.48 1568
(160)		 3.28 1441
(147)		 4.02 1343
(137)		 4.69 1274
(130)		 5.34 2940
(300)		 3920
(400)		 7840
(800)		 45 3920
(400)		 7840
(800)		 1′ 392(40) 26.4
101 100
129 128
145 144
171 170
WRV320E
WRV320E3		 81 80 4361
(445)		 3.04 3538
(361)		 4.94 3136
(320)		 6.57 2881
(294)		 8.05 2695
(275)		 9.41 2548
(260)		 10.7 4900
(500)		 7056(720) 14112
(1440)		 35 7840(800) 15680(1600) 1′ 980
(100)		 44.3
101 100
118.5 117.5
129 128
141 140
153 152
171 170
185 184
201 200
WRV450E 81 80 6135
(626)		 4.28 4978
(508)		 6.95 4410
(450)		 9.24 4047
(413)		 11.3 3783
(386)		 13.2 7448
(760)		 8820(900) 17640
(1800)		 25 11025
(1125)		 22050
(2250)		 1′ 1176
(120)		 66.4
101 100
129 128
153 152
171 170
192.4 191.4
201 200
210.23 209.23
257.84 256.84
